End of Life Notice
* Effective Date: 2021/10/07
» Intel® Xeon® W family processor supported
» 6 x PCIe Slot, up to 4 dual width GPU cards
» Water cooling system on CPU
» Support two U.2 SSD
» Support one M.2 SSD M-key slot ( NVMe PCIe 3.0 x4 )
» Support 10GbE network
» IPMI remote management
Hardware Spec.
| 规格 | |
|---|---|
| 规格 | 4U, Rackmount |
| 系统 | |
| CPU | Intel® Xeon® W Family Processors |
| 芯片组 | Intel® C422 |
| 内存上限 | Memory expandable up to: 256 GB (64 GB x 4) |
| 散热方式 / 系统风扇 | 2 x Smart Fan (12cm 12V DC) |
| 物理特性 | |
| 机架高度 | 4U |
| 尺寸 (LxWxH) (mm) | 176.15 x 480.94 x 644 |
| 存储 | |
| 存储 | 8 x 2.5” SSD/HDD Bay |
| 12 x 3.5” HDD Bay | |
| 1 x M.2(NGFF) | |
| 20 x SATA | |
| 2 x U.2 | |
| I/O 接口 | |
| 显示输出 | 1 x VGA |
| 以太网 | 2 x LAN(1 x 1GbE RJ45 combo LAN ports / IPMI; 1 x 10GbE RJ45 LAN port) |
| I/O 接口 | 1 x External RS-232 |
| 2 x External USB 2.0 | |
| 4 x External USB 3.0 | |
| 1 x Internal RS-232 | |
| 1 x Internal USB2.0 | |
| 1 x Internal USB3.0 | |
| 扩展 | 2 x PCIe x 4(PCIe 3.0) |
| 4 x PCIe x 8(PCIe 3.0) | |
Ordering Information
| GRAND-C422-20D-S1E4-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2195 with C422 chipset, 256G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
|---|---|
| GRAND-C422-20D-S1D3-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2155 with C422 chipset, 128G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
| GRAND-C422-20D-S1C3-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2145 with C422 chipset, 128G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
| GRAND-C422-20D-S1B2-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2133 with C422 chipset, 64G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
| GRAND-C422-20D-S1A1-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2123 with C422 chipset, 32G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
Package Contents
| Package Content |
|
|---|
