End of Life Notice
* Effective Date: 2021/09/09
» RoHS compliant design
» Two USB ports on the front panel
» One 8 cm hot swappable fan
» One 3.5” internal HDD bay
» One 3.5” drive bay, for optional removable drive
» Supports half-size CPU card and expansion card (maximum up to 169 mm)
Hardware Spec.
| Form factor | |
|---|---|
| SBC Form Factor | Half-size, slot SBC |
| I/O Interface | |
| I/O Openings | 1 x LPT, 1 x COM |
| I/O Ports | 2 x USB |
| Expansion Slots | |
| Expansion Slots | 5 slots |
| System | |
| Cooling method / System Fan | 1 x 8 cm system fan |
| Drive Bays | 1 x 3.5” HDD |
| Indicator&Buttons | |
| Buttons |
1 x Power Switch 1 x Reset Button |
| Indicators | HDD & Power |
| Physical Characteristics | |
| Construction | Heavy Duty Metal |
| Color | |
| Color | Navy Blue & Black |
| Dimensions | |
| Dimensions | 268.7mm x 140mm x 230.3mm (WxDxH) |
| Weight | |
| Weight | 3.8 kg/5.6 kg(Net/Gross) |
| Environment | |
| Operating Temperature | 0°C~+50°C |
| Humidity | 10% ~ 95%, non-condensing |
Ordering Information
| PAC-400AI-R10/FSP250 | 5-Slot Half size Industrial Chassis,Navy Blue and Black,1x 8cm fan,with FSP250(250W),RoHS |
|---|---|
| PAC-400AI-R10/A618B | 5-Slot Half size Industrial Chassis,Navy Blue and Black,1x 8cm fan,with ACE-A618B-RS-R10(180W),RoHS |
Package Contents
| Package Content |
|
|---|
