» 宽输入范围 6-36 VDC
» 可选输出电压+12V、+19V或+24VDC
» 宽温度范围-20 ~ +70°C
» 高效率可达98%
» 紧凑型设计
» 适用于机箱安装的导热垫
Hardware Spec.
| Input | |
|---|---|
| Voltage | 6-36V DC |
| Output | |
| Voltage | 12 或 19 或 24V DC可通过拨码选择 |
| General | |
| Watt | 160W (Max. total output) |
| Efficiency | 0.98 |
| Operating temperature | -20ºC ~ 70ºC |
| Storage temperature | -40ºC ~ 84ºC |
| Dimensions | 40 x 95 x 19.25 mm |
Ordering Information
| IDD-636160S-R10 | 160W DC/DC 6~36V input, multiple 12/19/24V output power module, RoHS |
|---|
