» RoHS compliant design
» One 5.25” and one 3.5” drive bay
» Two 3.5” internal HDD bays
» Seven expansion slots, compatible with full-size SBC
» 7 expansion slots, compatible with full-size SBC
Hardware Spec.
| Form factor | |
|---|---|
| SBC Form Factor | Full-size, slot CPU card |
| I/O Interface | |
| I/O Openings | 1 x LPT, 2 x COM |
| Expansion Slots | |
| Expansion Slots | 7 slots |
| System | |
| Cooling method / System Fan | 1 x 8 cm |
| Drive Bays |
1 x front-accessible 3.5" 1 x 5.25" 2 x 3.5" HDD |
| Indicator&Buttons | |
| Buttons | Power switch, reset |
| Indicators | Power, HDD |
| Physical Characteristics | |
| Construction | Metal with plastic front panel |
| Color | |
| Color | B: Black |
| Dimensions | |
| Dimensions | 433 mm x 233 mm x 253.7 mm(DxWxH) |
| Weight | |
| Weight | 6 kg/8.4 kg(Net/Gross) |
| Environment | |
| Operating Temperature | 0°C ~ 50°C |
| Humidity | 10% ~ 90% |
Ordering Information
| PAC-1700GBPX-R30/300W | 7-Slot Full-size Chassis,Black,Powder paint,1x 8cm fan,with 300W ATX PSU,RoHS |
|---|---|
| PAC-1700GBPX-R30 | 7-Slot Full size Chassis,Black,Powder paint,W/O PSU,RoHS |
