End of Life Notice
* Effective Date: 2017/12/29
» 内置双核 Intel® Atom™ D525 处理器
» 宽范围 9 V~36 V DC 电源输入
» 隔离保护 COM 和 CAN 通信
» 扩展温度无风扇设计支持 -20°C ~ 70°C (N455)
Hardware Spec.
| 颜色 | |
|---|---|
| 颜色 | Cool Gray+Blue |
| 尺寸 | |
| 尺寸 | 248 x 138 x 44 |
| 运行环境 | |
| 湿度 | 5% ~ 95%, non-condensing |
| 操作温度 |
-20°C~60°C (D525 with air flow CF/SSD), -20°C~70°C (N455 with air flow CF/SSD), |
| 扩展插槽 | |
| 扩展插槽 | PCIe Mini:1 x Full size |
| 形态系数 | |
| SBC 形态系数 |
CPU: Intel® Atom™ D525 1.8 GHz Intel® Atom™ N455 1.66 GHz Chipset:Intel® ICH8M System Memory On-board DDR3 1 GB memory 1 x 204-pin DDR3 SDRAM SO-DIMM(system max: 3 GB) |
| I/O 接口 | |
| I/O 端口 |
4 x USB 2.0 Ethernet: 2 x RJ-45 PCIe GbE by Realtek 8111E COM Port 3 x RS-232 (DB-9) 1 x RS-422/485(DB-9, Default RS-422 with isolation) CAN Bus:2 x DB-9 CAN with isolation Display:1 x VGA Resolution:VGA: Up to 2048 x 1536@60Hz Audio:1 x Line-out, 1 x Mic-in Wireless:1 x 802.11b/g/n (optional) |
| 系统 | |
| 散热方式 / 系统风扇 | Fanless |
| 驱动仓 | 1 x 2.5' SATA 3Gb/s HDD/SSD bay |
| 重量 | |
| 重量 | 2.1 kg/3.9 kg |
Ordering Information
| TANK-101B-R11/N455/1GB | Extend tempeture Fanless embedded system with Intel? ATOM? Processor N455 1.66GHz CPU with two isolated CAN, One isolated Serial Port, 1GB DDR3 memory onboard, 9~36V DC in, Pantone 287C + Cool Gray 2C, -20°C ~ 70° C, RoHS |
|---|---|
| TANK-101B-R11/D525/1GB | Extend tempeture Fanless embedded system with dual core Intel ATOM Processor D525 1.8G CPU with two isolated CAN, One isolated Serial Port, 1GB DDR3 memory onboard, 9~36V DC in, Pantone 287C + Cool Gray 2C ,-20°C ~ 60°C, RoHS |
Package Contents
| Package Content |
|
|---|
