End of Life Notice
* Effective Date: 2018/12/13
» RoHS compliant design
» One 3.5” drive bay
» Two USB ports on the front panel
» One, 6 cm cooling fan
Hardware Spec.
| Form factor | |
|---|---|
| SBC Form Factor | Half-size, slot SBC |
| I/O Interface | |
| I/O Openings | 1 x LPT, 1 x COM |
| I/O Ports | 2 x USB |
| Expansion Slots | |
| Expansion Slots | 3 slots |
| System | |
| Cooling method / System Fan | 1 x 6 cm |
| Drive Bays | 1 x 3.5” (front accessible/HDD) |
| Indicator&Buttons | |
| Buttons | Power switch, reset |
| Indicators | Power, HDD |
| Physical Characteristics | |
| Construction | Heavy duty metal |
| Color | |
| Color | W: White/B: Black |
| Dimensions | |
| Dimensions | 254 mm x 265 mm x 95.5 mm |
| Weight | |
| Weight | 2.6 kg/5.2 kg |
| Environment | |
| Operating Temperature | 0°C ~ 50°C |
| Humidity | 10% ~ 90% |
Ordering Information
| PR-1300GW-R11 | 3-Slot Half size Chassis,White color,W/O BP,W/O PSU,RoHS |
|---|---|
| PR-1300GW-R11/A618B | 3-Slot Half size Chassis,White,1x 6 cm fan,with ACE-A618B-RS-R10(180W),RoHS |
