End of Life Notice
* Effective Date: 2021/02/23
» Support Android 5.0
» Flexibie ID Design.(Open Frame or customized ID Design)
» IEI Customer Reference Board(10.1” / 15.6” / 18.5” share the same main board)
» Freescale Quad Core - A9 1GHz processor
» 10.1” / 15.6” / 18.5” Color TFT LCD
» Waterproof:IPX5(For customized ID)
» Support BLE / ANT + NFC
» Support ATSC / DVBT TV Dongle
Hardware Spec.
| Communication | |
|---|---|
| Bluetooth | BT4.0 |
| Wi-Fi | 802.11 b/g/n |
| Environment | |
| Humidity | 5%~95% |
| Operating Temperature | 0°c~+40°c |
| Storage Temperature | -10°c~+50°c |
| LCD | |
| Backlight MTBF | 50000 |
| Brightness (cd/m2) | 300 (cd/m²) |
| Contrast Ratio | 500:1 |
| LCD Color | 16.7M |
| Pixel Pitch (mm) | 0.2525 x 0.252 |
| Resolution | 1366 (W) x 768 (H) |
| Size | 15.6” |
| Other Features | |
| Audio | 2 x 3W Audio |
| Physical Characteristics | |
| Color | Black |
| Dimensions (LxWxH) (mm) | 420 x 270 x 87mm |
| Power | |
| Power consumption | 12V @2.25A |
| Power Requirement | 12~36V |
| System | |
| CPU | Freescale iMX6 Cortex-A9 Quad Core 1.0 GHz |
| Memory Max. | 2GB DDR3 SDRAM |
| SBC Model | OS Support:Android 5.1 |
| Touch | |
| Touch Screen | Projected capacitive flat touch |
| I/O Interface | |
| I/O Interface | 1 x USB 2.0 |
| 1 x HDMI™ | |
| 1 x LAN(10/100 Mbps Power over Ethernet) | |
| 1 x SD Slot | |
