Mustang-V100-MX4

具有 4 个 Intel® Movidius™ Myriad™ X MA2485 VPU 的计算加速卡,PCIe Gen 2 x 2 接口,RoHS

Mustang-V100-MX4 Accelerator Card
Mustang-V100-MX4 Accelerator Card
Mustang-V100-MX4 Accelerator Card
  • Mustang-V100-MX4 Accelerator Card
  • Mustang-V100-MX4 Accelerator Card
  • Mustang-V100-MX4 Accelerator Card
» PCIe Gen 2 x 2 外形尺寸
» 4 个 Intel® Movidius™ Myriad™ X VPU MA2485
» 电源功率,约 15W
» 操作温度 -20°C~60°C
» 由 Intel 的 OpenVINO™ 工具包提供支持
» 支持多张卡

Hardware Spec.

System
Chipset 4 x Intel® Movidius™ Myriad™ X MA2485 VPU
Cooling method / System Fan Active fan
Physical Characteristics
Dimensions (LxWxH) (mm) 113 X 56 X 23
Power
Power Consumption Approximate 15W
Environment
Operating Temperature -20°C ~ 60°C
Humidity 5% ~ 90%
Card Slot Interface
PCIe Gen 2 x 2

Ordering Information

Mustang-V100-MX4-R10 Computing Accelerator Card with 4 x Intel® Movidius™ Myriad™ X MA2485 VPU, PCIe Gen2 x2 interface, RoHS

Package Contents

Package Content
  • 1 x 全高支架
