End of Life Notice
* Effective Date: 2023/07/03
* Reading distance: up to 30mm
* Frequency: 13.56 MHz
* Support ISO14443A read, ISO15693 read/write ,Mifare DESFire EV1 8k
* USB interface
* Support RFID software development tool
* AFL3-MF-RFID-KIT01 for AFL3-W07A-BT
* AFL3-MF-RFID-KIT02 for AFL3-BT and AFL3-AL series, except to AFL3-W07A
Hardware Spec.
| Environment | |
|---|---|
| Operating Temperature | 0°C ~ 50°C |
| Storage Temperature | -10°C ~ 70°C |
| General | |
| Dimensions | 22mmX 50mm X7mm |
| Description | |
| Description |
* AFL3-MF-RFID-KIT01 for AFL3-W07A-BT * AFL3-MF-RFID-KIT02 for AFL3-BT and AFL3-AL series, except to AFL3-W07A |
| Interface | |
| Interface | USB 2.0 full speed with 3.3/5V logic levels |
| Key Features | |
| Key Features |
* Reading distance: up to 30mm * Frequency: 13.56 MHz * Support ISO14443A read, ISO15693 read/write ,Mifare DESFire EV1 8k * USB interface * Support RFID software development tool |
Ordering Information
| AFL3-MF-RFID-KIT02-R10 | AFL3 PPC Mifare RFID reader kit, for AFL3-BT / AFL3-AL / AFL3-ULT3 , R10 |
|---|---|
| AFL3-MF-RFID-KIT01-R10 | AFL3 PPC Mifare RFID reader kit, for AFL3-W07A-BT , R10 |
