紧凑型嵌入式电脑

Fanless Ultra Compact Size

Space-saving demand in industrial environment is very common in nowadays. Many applications require a small space for system installation. With the palm-size embedded box design plus its basic IO interface can definitely meet the space-saving requirement.
CPU
I/O
Expansion

ITG-100-AL

无风扇超紧凑型嵌入式系统
Intel® Atom™ x5-E3930 1.3GHz (上限 1.8 GHz, 双核, TDP=6.5W)
Intel® Atom™ x5-E3930 1.3GHz (上限 1.8 GHz, 双核, TDP=6.5W)
●USB: 2 x USB 3.0
●以太网:2 x RJ-45
PCIe GbE by Intel® I211 控制器
●COM 端口:2 x RS-232/422/485
●显示:1 x VGA
●USB: 2 x USB 3.0
●以太网:2 x RJ-45
PCIe GbE by Intel® I211 控制器
●COM 端口:2 x RS-232/422/485
●显示:1 x VGA
M.2:
1 x M.2 2230 (A key, PCIe by 1, USB2.0)
PCIe Mini:
1 x 全尺寸 PCIe Mini 插槽 (支持 mSATA, colay with SATA)
M.2:
1 x M.2 2230 (A key, PCIe by 1, USB2.0)
PCIe Mini:
1 x 全尺寸 PCIe Mini 插槽 (支持 mSATA, colay with SATA)
View Products

uIBX-250-BW

Ultra Compact Size
Intel® Celeron® N3160
(up to 2.24 GHz, quad-core, 2 MB cache, TDP=6W)
Intel® Celeron® N3160
(up to 2.24 GHz, quad-core, 2 MB cache, TDP=6W)
4 x USB 3.0
2 x RJ-45 PCIe GbE by Intel® i210 controller
2 x RJ-45 RS-232/422/485
1 x HDMI™, 1 x VGA
1 x Line-out, 1 x Mic-in
4 x USB 3.0
2 x RJ-45 PCIe GbE by Intel® i210 controller
2 x RJ-45 RS-232/422/485
1 x HDMI™, 1 x VGA
1 x Line-out, 1 x Mic-in
1 x Full-size PCIe Mini card (co-lay mSATA)
1 x Full-size PCIe Mini card (co-lay mSATA)
View Products

uIBX-260-EHL

超紧凑尺寸
● CPU:
Intel® Celeron J6412 2GHz (up to 2.6 GHz, 四核, TDP 10W)
● CPU:
Intel® Celeron J6412 2GHz (up to 2.6 GHz, 四核, TDP 10W)
● USB:
2 x USB 3.2 Gen2
2 x USB 2.0 (可选)
● 网络:
2 x RJ-45 2.5 GbE by I225V controller
● 显示:
1 x HDMI™ 1.4b (up to 4k@ 30Hz)
● 串口:
1 x RS-232/422/485 (DB9)
1 x RS-232 (可选)
● TPM:
支持Intel PTT
● 无线/蓝牙:
1 x 802.11a/b/g/n/ac (M.2 A Key可选)
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● USB:
2 x USB 3.2 Gen2
2 x USB 2.0 (可选)
● 网络:
2 x RJ-45 2.5 GbE by I225V controller
● 显示:
1 x HDMI™ 1.4b (up to 4k@ 30Hz)
● 串口:
1 x RS-232/422/485 (DB9)
1 x RS-232 (可选)
● TPM:
支持Intel PTT
● 无线/蓝牙:
1 x 802.11a/b/g/n/ac (M.2 A Key可选)
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● M.2:
1 x 2230 A-key (PCIe Gen3 x1/ USB2.0)
1 x 2280 M-key (PCIe Gen3 x2)
● M.2:
1 x 2230 A-key (PCIe Gen3 x1/ USB2.0)
1 x 2280 M-key (PCIe Gen3 x2)
View Products

TANGO Series

The TANGO series is an industrial mini PC in a space-saving design. With light, small but robust chassis ensuring durability and reliability, the mini PC can be set up in an instant and taken almost anywhere, even in harsh environment. It is ideal for enterprises, digital signage, industrial data transmission gateway and self-service applications.
CPU
I/O
Expansion

TANGO-3010

超紧凑尺寸
● CPU:
Intel® Celeron J6412 2GHz (up to 2.6 GHz, 四核, TDP 10W)
● CPU:
Intel® Celeron J6412 2GHz (up to 2.6 GHz, 四核, TDP 10W)
● USB:
2 x USB 3.2 Gen2
2 x USB 2.0
● 网络:
3 x RJ-45 2.5 GbE by I225V controller
● 显示:
2 x HDMI™
● 串口:
1 x RS-232 (DB9)
1 x RS-232/422/485 (DB9)
● TPM:
支持Intel PTT
● 无线/蓝牙:
INTEL AX210 WiFi 6E &蓝牙5.2模块带 2T2R天线
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● USB:
2 x USB 3.2 Gen2
2 x USB 2.0
● 网络:
3 x RJ-45 2.5 GbE by I225V controller
● 显示:
2 x HDMI™
● 串口:
1 x RS-232 (DB9)
1 x RS-232/422/485 (DB9)
● TPM:
支持Intel PTT
● 无线/蓝牙:
INTEL AX210 WiFi 6E &蓝牙5.2模块带 2T2R天线
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● M.2:
1 x 2230 A-key (PCIe x1/USB2.0)(预装无线模块)
1 x 2280 M-key (PCIe x4)
● M.2:
1 x 2230 A-key (PCIe x1/USB2.0)(预装无线模块)
1 x 2280 M-key (PCIe x4)
View Products

TANGO-7010

紧凑尺寸
12th Intel® Core™ i Processors
12th Intel® Core™ i Processors
● USB:
2 x USB3.2 Gen2
2 x USB3.2 Gen1
● 网络:
3 x RJ-45 2.5 GbE by I225V controller
● 显示:
2 x HDMI™ 2.0B Support CEC (up to 4k@ 60Hz)
1 x DP 1.4 (up to 4k@ 60Hz)
● 串口:
1x RS-232 (DB9)
1x RS-232/422/485 (DB9)
● TPM:
支持Intel PTT
● 无线/蓝牙:
INTEL AX210 WiFi 6E &蓝牙5.2模块带 2T2R天线
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● USB:
2 x USB3.2 Gen2
2 x USB3.2 Gen1
● 网络:
3 x RJ-45 2.5 GbE by I225V controller
● 显示:
2 x HDMI™ 2.0B Support CEC (up to 4k@ 60Hz)
1 x DP 1.4 (up to 4k@ 60Hz)
● 串口:
1x RS-232 (DB9)
1x RS-232/422/485 (DB9)
● TPM:
支持Intel PTT
● 无线/蓝牙:
INTEL AX210 WiFi 6E &蓝牙5.2模块带 2T2R天线
● 看门狗定时器:
可编程1 ~ 255 秒/分钟
● M.2:
1 x 2230 E-key (PCIex1/USB2.0)(预装无线模块)
1 x 2280 M-key (PCIe Gen4 x4)
1 x 2280 M-key (PCIe Gen3 x4)
● M.2:
1 x 2230 E-key (PCIex1/USB2.0)(预装无线模块)
1 x 2280 M-key (PCIe Gen4 x4)
1 x 2280 M-key (PCIe Gen3 x4)
View Products
