» 英特尔灵动系列 X7433RE / X7835RE 处理器
» 10~28V 宽压输入
» 304不锈钢机身外壳
» 预装一根高性能8GB DDR5内存，可高达 16GB
» WiFi 6E 和蓝牙 5.2可选配
» 高速传输光纤模块可选配
» M12全防水接口
Hardware Spec.
| System | |
|---|---|
| CPU |
Intel Atom® x7433RE Processor 6M Cache, up to 3.40 GHz / TDP 9w Intel Atom® x7835RE Processor 6M Cache, up to 3.40 GHz / TDP 12w |
| Memory Ext. | 一根 SO-DIMM DDR5-4800 插槽，可高达 16GB (预装 8GB，支持 ECC) |
| 存储 |
1 x M-Key 2280 (PCIe Gen3 x2) for M.2 SSD 1 x 128GB Emmc ( 选配 ) |
| Communication | |
| 无线 |
IEEE 802.11ax 2T2R module (Wi-Fi 6E) with BT v5.2 (选配) |
| I/O Interface | |
| 网络 | 2 x 2.5GbE LAN via Intel I226-IT |
| 扩展 |
1 x M.2 M-Key 2242/2280 (PCIe Gen3 x1 + SATA) 1 x M.2 B-Key 3052/3080 (PCIe Gen3 x1 + USB 3.0 x1) 1 x NANO-SIM 1 x M.2 E-key 2230 (PCIe Gen3 x1 + USB 2.0 x1) for optional WIFI/BT module |
| Power | |
| Power Supply | 10 ~ 28V直流 |
| Environment | |
| 工作温度 | -30°C~55°C@50%RH |
| 安规&电磁 | CE, FCC (Class A) |
| 相对湿度 | 10% ~ 90% ( 无冷凝) |
| 存储温度 | -40°C ~ 70°C |
| IP Level | 全机身符合 IP66 防护等级 |
| Physical Characteristics | |
| 机身颜色 | silver |
| 安装方式 | Yoke / VESA 100mm |
| LCD | |
| LCD 尺寸 | 18.5” |
| 分辨率 | 1920 x 1080 (16:9) |
| 亮度 | 500 cd/m² |
| 对比度 | 1000 : 1 |
| LCD 色彩 | 16.7M |
| 像素间距 (mm) | 0.213 (H) x 0.213 (V) |
| 可视角度 (H-V) | 178°/178° |
| 背光 MTBF | 50000 小时 |
| Touch | |
| 触摸屏 | PCAP with USB interface (anti-UV/AR coating) |
| 触控IC | ILI2520 |
| Other Features | |
| Camera | 1 x Camera (Wide-viewing angle) |
| I/O Interface | |
| I/O 接口 | 1 x CAN-bus (with 2.0 kV isolation) |
| 1 x Power Switch | |
| 1 x RS-232 (with 2.0 kV isolation) | |
| 1 x RS-232/422/485 (with 2.0 kV isolation) | |
| 1 x USB 2.0 | |
| 1 x USB 3.2 Gen1x1 | |
| 1 x HDMI™ (1.4b) | |
| 2 x LAN (2.5GbE) | |
| 1 x DC Input Jack | |
| 1 x GPIO (with SMbus (1.6 KV isolation)) | |
Ordering Information
| SHIELD-185-R4C-R10 | 18.5" 500cd/m² 1920x1080 Panel PC with Intel® Atom x7835RE Processor, TDP 12W, Preinstalled with 8GB DDR5, PCAP touch, 10~28V DC, 304 Stainless Steel Chassis, Full body IP66 Rated with water-proof Connectors , R10 |
|---|---|
| SHIELD-185-R3C-R10 | 18.5" 500cd/m² 1920x1080 Panel PC with Intel® Atom x7433RE Processor, TDP 9W, Preinstalled with 8GB DDR5, PCAP touch, 10~28V DC, 304 Stainless Steel Chassis, Full body IP66 Rated with water-proof Connectors , R10 |
Package Contents
| Package Content |
|
|---|
