嵌入式系统

● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)

● USB:
2 x USB 3.2 Gen2
2 x USB 2.0
● 网络:
1 x GbE by Intel® I210-AT controller
3 x 2.5 GbE by Intel® I225-V/I226-V controller
● 显示:
1 x HDMI™ 1.4B
● COM Port:
1 x RS-232/422/485 (DB9)(选配)
● TPM:
支持 Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x 2242 B-key (PCIe Gen3 x2)
1 x 2242 B-key (SATA)
1 x 2280 M-key (PCIe Gen3 x2)

● Supported CPU:
Intel® Celeron® J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)

● USB:
4 x USB 3.2 Gen2
● 网络:
2 x 2.5 GbE by Intel® I225-V/I226-V controller
● 显示:
2 x HDMI™ (up to 4K@30Hz)
● COM Port:
4 x RS-232/422/485 (DB-9)
● Digital I/O:
8-bit Digital I/O (4-in/ 4-out)
● CAN BUS:
2 x CAN-bus (DB9 带2.5kV隔离)
● Wireless:
1 x 802.11a/b/g/n/ac (选配)
● TPM:
1 x TPM (2 x10 pin)
Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x M.2 A Key 2230 (PCIe Gen3 x1/USB 2.0)
1 x M.2 M Key 2280 (PCIe Gen3 x2)

● Supported CPU:
Intel® Core™ i7-1370PE (up to 4.8GHz, 14-core, 28W TDP)
Intel® Core™ i7-1260P (up to 4.7GHz, 12-core, 28W TDP)
Intel® Core™ i5-1340PE (up to 4.5GHz, 12-core, 28W TDP)
Intel® Core™ i5-1240P (up to 4.4GHz, 12-core, 28W TDP)
Intel® Core™ i3-1320PE (up to 4.5GHz, 8-core, 28W TDP)
Intel® Core™ i3-1220P (up to 4.4GHz, 10-core, 28W TDP)
Intel® Celeron® 7305 (5-core, 15W TDP)

● USB:
2 x USB 3.2 Gen2
4 x USB 2.0
● 网络:
1 x 2.5 GbE by Intel® I225LM/I226LM controller support iAMT
2 x 2.5 GbE by Intel® I225-V/I226-V controller
● 显示:
1 x lockable HDMI™ 1.4b (up to 4096 x 2160@30Hz)
1 x DP 1.4b (up to 4096 x 2160 @60Hz)
● COM Port:
2 x RS-232 (DB9 with 2.5KV isolation)
2 x RS-232 (选配)
2 x RS-422/485 with AFC (DB9 with 2.5KV isolation)
● GPIO:
1 x 12-bit(6-in, 6-out)(选配)
● TPM:
支持 Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x 2230 A-key (PCIe Gen3 x1/USB 2.0) Support Vpro
1 x 3042/52 B-key (PCIe Gen3 x1/USB 3.2 Gen2/USB 2.0)
1 x 板载SIM 卡槽 (hinge type) for M.2 B key
1 x 2280 M-key (PCIe Gen4 x4)
● Backplane:
1 x PCIe Gen3 x4 (选配)

● Supported CPU:
Intel® Celeron™ J6412 2.0 GHz (up to 2.6 GHz, quad-core, TDP 10W)

● USB:
2 x USB 3.2 Gen 2
● 网络:
2 x 2.5 GbE by Intel® I225V (colay I225LM)
● 显示:
1 x HDMI™
1 x DP
● TPM:
支持 Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x M.2 A Key 2230 for WIFI & BT (选配)
1 x M.2 B Key (PCIe x2) 3042 w/SIM slot for 5G (选配)

Intel® Celeron® N5105 2.0 GHz (up to 2.9 GHz, quad-core, TDP 10W)

● USB:
2 x USB 3.2 Gen 2
● 网络:
3 x 2.5 GbE by Intel® I225V (colay I225LM)
● 显示:
1 x HDMI™
1 x DP
● TPM:
支持 Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x M.2 A Key 2230 for WIFI & BT (选配)
1 x M.2 B Key (PCIe x2) 2242/2280 w/SIM slot for 5G (选配)

● Supported CPU:
Intel® Core™ i7-1185G7E 1.8 GHz (up to 4.4 GHz, quad-core, TDP 15W)
Intel® Core™ i5-1145G7E 1.5 GHz (up to 4.1 GHz, quad-core, TDP 15W)
Intel® Core™ i3-1115G4E 2.2 GHz (up to 3.9 GHz, dual-core, TDP 15W)
Intel® Celeron® 6305/6305E 1.8 GHz (dual-core, TDP 15W)

● USB:
4 x USB 3.2 Gen 2
● 网络:
3 x 2.5 GbE by Intel® I225V (colay I225LM)
● 显示:
2 x HDMI™
1 x DP
● TPM:
支持 Intel PTT
● 看门狗定时器：
可编程 1 ~ 255 秒/分钟

● M.2:
1 x M.2 A Key 2230 for WIFI & BT (选配)
1 x M.2 B Key (PCIe x2) 3042/3052 w/SIM slot for 5G (选配)

Intel® Celeron® 6305/6305E 1.8 GHz
Intel® Core™ i5-1145G7E 1.5 GHz
Intel® Core™ i7-1185G7E 1.8 GHz

●USB:
2 x USB 3.2 Gen 2
2 x USB 2.0
●Ethernet: 4 x RJ-45
1 x 2.5 GbE by Intel® I225LM
3 x 2.5 GbE by Intel® I225V
●COM Port:
2 x RS-422/485 with AFC
2 x RS-232
●Digital I/O:
12-bit Digital I/O
●显示:
1 x HDMI™
1 x DP++
●TPM:
支持Intel PTT
●看门狗:
可编程 1 ~ 255 秒/分钟

●M.2:
1 x 2230 A-key
1 x 3042/52/80 B-key
1 x 板载SIM卡槽(适用于M.2 B Key)
●背板:
1 x PCIe x4

Intel® Atom™ x5-E3930 1.3GHz

●USB:4 x USB 3.0
●Ethernet:2 x RJ-45
●COM Port:4 x RS-232/422/485
●Digital I/O:8-bit digital I/O , 4-bit input / 4-bit
●CAN-Bus:1 x DB-9 w/ 2.5kV Isolation protection, supporting 2-port CAN-bus
●Display:2 x HDMI™ 1.4b

PCIe Mini:
1 x Half-size PCIe Mini slot
1 x Full-size PCIe Mini slot
